Flanged Heaters

Catalonia Heaters range of immersion heaters is suitable for heating all process fluids

Category:

Description

Catalonia Heaters range of immersion heaters is suitable for heating all process fluids, which are non-corrosive to the materials of construction. Flanged immersion heaters are hairpin-bent tubular elements, welded to a flange, provided with electrical safety devices and a suitable junction Box.

Typical Applications:

  • Fresh Water
  • Sea Water
  • Crude Oil
  • Process Gas
  • Air
  • Tank Heating
  •  Synthetic Oils
  • Heating Medium
  • Vapour-liquid separators
  • Glycol Re boilers
  • Butane/Propane Vaporizer
  • Molecular Sleeve Regeneration



Technical Description:

  • For heating liquids and gases, the enclosure is produced in Carbon steel or Stainless steel
  • Up to 60″ flange, acc. ANSI B 16.5, in the following materials: carbon steel, stainless steel, nickel alloys, Inconel, etc.
  • Degree of protection of the enclosure: IP40, IP55, IP65, IP66, IP67
  • Standard diameter of heating elements: 8.5, 12.5 & 16 mm
  • Material of elements: Carbon steel, 304(L), 316(L) or 321 SST, Incoloy 800 or 825, Inconel 600 or 625, Hastelloy, Monel. Copper Immersion length: up to 4 meters. Power rating: up to 8000 kW



The electric heater bundle can be provided with:

1- Protective and/or control devices: thermostats, thermocouples or PT100;

2- Temperature transmitters;

3- Anti condensation heaters;

4- Cable glands.
